The MFRC522's internal transmitter part is able to drive a reader/writer antenna designed to communicate with ISO/IEC 14443A/MIFARE® cards and transponders without additional active circuitry for signals from ISO/IEC 1443A/MIFARE® compatible cards and transponders. The digital part handles the complete ISO/IEC 14443A framing and error detection (Parity and CRC). The MFRC522 supports MIFARE®Classic (e.g. MIFARE® Standard) products. The MFRC522 supports contactless communication using MIFARE® higher transfer speeds up to 848 kbit/s in both directions.
- Interface:I²C, SPI, UART
- Operating Temperature:-25°C ~ 85°C
- Package / Case:32-VFQFN Exposed Pad
- Standards:ISO 14443, MIFARE
- Supplier Device Package:32-HVQFN (5x5)
- Type:RFID Reader
- Voltage - Supply:2.5 V ~ 3.3 V
