IRFR3708 TO252 MOSFET N-CH 30V 61A

5.500₫

Còn hàng



IRFR3708 TO252 MOSFET N-CH 30V 61A

Datasheets IRFR3708, IRFU3708
Product Photos TO-263
Design Resources
Standard Package ? 75
Category
Family FETs - Single
Series HEXFET®
Packaging ? Tube ?
FET Type MOSFET N-Channel, Metal Oxide
FET Feature Logic Level Gate
Drain to Source Voltage (Vdss) 30V
Current - Continuous Drain (Id) @ 25° C 61A (Tc)
Rds On (Max) @ Id, Vgs 12.5 mOhm @ 15A, 10V
Vgs(th) (Max) @ Id 2V @ 250µA
Gate Charge (Qg) @ Vgs 24nC @ 4.5V
Input Capacitance (Ciss) @ Vds 2417pF @ 15V
Power - Max 87W
Mounting Type Surface Mount
Package / Case TO-252-3, DPak (2 Leads + Tab), SC-63
Supplier Device Package D-Pak
Other Names *IRFR3708
